3.DisassemblyandReassembly

3.3.ReplacingtheMainSVCparts

NOTE

Thecolorofmachinemaydifferfromyourmachinedependingonitsmodel.

3.3.1.RightandLeftcover

1.Remove2screwsfromtherear.

2.Releasetherightcover.

3.Releasetheleftcover.
