Samsung M2070F - Scanner Unit

3.DisassemblyandReassembly
3.3.2.ScannerUnit
1.Removetherightcover.(Referto3.3.1)
2.Unplugtheconnectorsconnectingthescanneruniton
themainboard.
3.OpentheScannerUnit.
4.Releasethescannerhingewhilepushingtheplaten
bottomconnectingit.
5.LiftupandreleasetheScannerUnit.
