4.AlignmentandTroubleshooting
4.AlignmentandTroubleshooting
4.1.AlignmentandAdjustments
Thischapterdescribesthemainfunctionsforservice,suchastheproductmaintenancemethod,thetestoutputrelatedto
maintenanceandrepair,Jamremovingmethod,andsoon.Itincludesthecontentsofuserguide.
4.1.1.ControlPanel
NOTE
•Thiscontrolpanelmaydifferfromyourmachinedependingonitsmodel.Therearevarioustypesofcontrolpanels.
•Somefeaturesandoptionalgoodsmaynotbeavailabledependingonmodelorcountry.
M2070/M2070W
6
4
5
3
2
1
7
1
0
1
2
1
3
1
4
1
1
9
8
1IDCopyAllowsyoutocopybothsidesofanIDcardlikeadriver’slicenseonasingleside
ofpaper.
2ScantoSwitchesbetweenscanandcopymode.TheScantoLEDturnsonscanmodeand
turnsoffoncopymode.
3DisplayscreenShowsthecurrentstatusanddisplayspromptsduringanoperation.
4MenuOpensMenumodeandscrollsthroughtheavailablemenus
5Left/RightArrowsScrollsthroughtheoptionsavailableintheselectedmenuandincreasesordecreases
values.
6Stop/ClearStopsanoperationsatanytime.
7Power/WakeupTurnsthepoweronoroff,orwakesupthemachinefromthepowersavemode.If
youneedtoturnthemachineoff,pressthisbuttonformorethanthreeseconds.
8StartStartsajob.
9PowerSaverGoesintopowersavemode.
10OKConrmstheselectiononthescreen.
11BackSendsyoubacktotheuppermenulevel.
12StatusLEDIndicatesthestatusofyourmachine.
13EcoTurnonEcomodetoreducetonerconsumptionandpaperusage
