Samsung M2070F - CIS Unit and Scan Drive Unit

3.DisassemblyandReassembly
3.3.5.CISUnitandScanDriveUnit
1.RemovetheScannerUnit/ADFUnit/OPEUnit.
(Referto3.3.2~3.3.4.
)
2.Remove2screwsfromthebottomoftheplaten.
3.Remove3screws.
4.Removetheplatenupperfromtheplatenlower.
5.UnplugtheCISatcable.ReleasetheCISUnit.
6.ReleasetheBelt-TimingGear.Remove3screws.And
releasetheScanDriveUnit.
