4.AlignmentandTroubleshooting

4.1.7.UpdatingFirmware

Thischapterincludesinstructionsforupdatingtheprinterrmware.Youcanupdatetheprinterrmwarebyusingone

ofthefollowingmethods:

•UpdatethermwarebyusingtheUSBport.

•UpdatethermwarebyusingtheNetwork.

4.1.7.1.UpdatethermwarebyusingtheUSBport

Upgradingpreparations

•usblist2.exe:Toolwhichsendsrmwaredatatoprinter.

•Firmwareletoupdate.

UpgradeProcedure

1)Turnthemachineoff.

2)ConnectUSBcabletoprinter.

3)Turnthemachineon.Checkiftheprinteristhereadystatus.

4)DragthermwareleandDropdownontheusblist2.exe.

Andthenrmwareupdatewillbestartedautomatically.

5)Whenupgradingiscompleted,machineisautomaticallyre-booting.
