Samsung M2070F - Electrical Parts Location

2.Productspecicationanddescription
2.2.5.6.ElectricalPartsLocation
1)Sensors
No.DescriptionControllerFunction
S2Photointerrupter(HomePositionsensor)MainboardCISdetection
S3SwitchFrontCoverSMP/HVPSboardCoveropendetection
S4Photointerrupter(widthSensor)MainboardPaperdetection
S5Photointerrupter(FeedSensor)MainboardPaperdetection
Copyright©1995-2013SAMSUNG.Allrightsreserved.2-31
