3.DisassemblyandReassembly

3.1.3.ReleasingPlasticLatches

Manyofthepartsareheldinplacewithplasticlatches.Thelatchesbreakeasily;releasethemcarefully.

Toremovesuchparts,pressthehookendofthelatchawayfromtheparttowhichitislatched.
