3.DisassemblyandReassembly

3.3.16.FeedSensorPBA

1.Removetherearcover.(Referto3.3.8)2.UnplugtheconnectorafterreleasingtheFeedSensor

PBA.

3.3.17.Pickuproller

1.Remove2screwsfromthebottom.2.Releasethepickuproller.
