2.Productspecicationanddescription
3)Emulationisthatinterpretsthevariousoutputdatafromselectedemulation.
4)Engineisthatprintsrenderedbit-mapdatatopaperwithrequiredsizeandtypebyKernel.
Andthen,forJobSpoolingfunctionforMulti-User,Multi-PrintingthatisoccurredinNetworkprintingandvarious
additionalprintingfunctions,thisKernelusemax.10Queuingsystemsinamemory.
InPrinting,thetwoproceduresare
1)CaseofusingUSBPort
•AfteruserstarttoprintthewanteddocumenttoPCLstringorcompressedGDIbit-mapdata,theDrivertranslates
theallgraphicdataoftheclientPCandsenddatatohostspooler.Andthenthespoolersendsthedatastreamto
theprinterviaUSBport.
•KernelreceivesthisdatafromHost,andthenselectemulationttodataandstartselectedone.Afteremulationjob
end,Kernelsendstheoutputbit-mapdatatoEngineusingPrinterVideoController(byclocktypeforLSU).
•Engineprintthereceiveddatatorequiredpaperwiththesequentialdevelopingprocess.
2)CaseofusingNetworkInterfaceCard
•AfteruserstarttoprintthewanteddocumenttoPCLstringorcompressedGDIbit-mapdata,Drivertranslatethe
allgraphicdataofitandsenddatatohostspooler.
•Ifso,PortmonitormanagingnetworkportreceivesdatafromspoolerandsendsadatastreamtotheNetwork
InterfaceCard.
•NetworkinterfacecardreceivesitandsendtoKernelpart.
•KernelreceivesthisdatafromHost,andthenselectemulationttodataandstartselectedone.Afteremulationjob
end,Kernelsendstheoutputbit-mapdatatoEngineusingPrinterVideoController(byclocktypeforLSU).
•Engineprintthereceiveddatatorequiredpaperwiththesequentialdevelopingprocess.
