4.AlignmentandTroubleshooting

►ErrorCode

11–2T11

►Errormessage

Tray1PaperMismatch

►Symptom

Tray1paperisnotproper.

►Troubleshootingmethod

Checkifthepapersettingisproper.Changethepapersettingorreplacethepaper.

►ErrorCode

C2–1110

C2–1120

C2–1150

C2–1160

►Errormessage

Preparenewtonercartridge.

Replacenewcartridge.

►Symptom

Theremainingtonercartridgeislessthan10%/Thetonercartridgeisattheendofitslife.

►Troubleshootingmethod

Printthesupplyinformationreport.

Checktheliferemainingofthetonercartridge.

Ifitslifeisattheend,turnthemachineoffandreplacethetonercartridgewithnewone.
