OfficeServ 7200-S INSTALLATION
TECHNICAL MANUAL PART 3 MAY 2010
3.4
Switches 1 through 4 select the country the system is installed in.
4 3 2 1 Country
OFF OFF OFF OFF Korea
OFF OFF OFF ON USA
OFF OFF ON OFF UK
OFF OFF ON ON Italy
OFF ON OFF OFF Australia
OFF ON OFF ON New Zealand
OFF ON ON OFF Holland
OFF ON ON ON Denmark
Switch 5 is reserved.
Any changes to these switch settings after system start up will require a full system default
by holding the RESET button in for 7 seconds. Without this system default RESET any
previous settings will be retained even if the system has been shut down and powered up
again.
3.2.2 Installing MP20S
Install processor boards in slot 0 of the cabinet. The locations of slot 0 through slot 5 are
described in figure 3.1.
Table 3.3 Types of Control Boards
Control Board Applicable Slot
MP20S Slot 0 of the cabinet
The installation procedure for the MP20S card is as follows:
1) Check the exterior of the MP20S card for any damage. If damage is found, do not proceed
with installation. Contact Samsung Technical Support.
Power the system OFF when installing or removing boards.
POWER TO THE CABINET MUST BE TURNED OFF. Failure to do so will damage the
card, cabinet and/or corrupt the data moving along the data bus.
