OfficeServ 7200-S INSTALLATION
TECHNICAL MANUAL PART 5 MAY 2010
5.15
SPECIFICATIONS OF OFFICESERV 7150
Specifications of Cabinet
Table 5.2 Input Voltage and Frequency
INPUT VOLTAGE & FREQUENCY
Rated AC Input Voltage Single phase AC 110/220VAC
Range of Allowable AC Input Voltage 88VAC ~ 264VAC
Rated AC Input Frequency 50/60 Hz
Range of Allowable AC Input Frequency 47Hz ~ 63Hz
Rated Output
Table 5.3 Rated Output in the Case of Operation with AC
RATED OUTPUT IN THE CASE OF OPERATION WITH AC
1 Module DC -54V, 7.5A
2 Module DC -54V, 15.0A
Battery DC 54V, 0.45A
Table 5.4 Rated Output in the Case of Operation with DC
RATED OUTPUT IN THE CASE OF OPERATION WITH DC
1 Module
Battery By-pass (DC 48V,48AH or lower), 7.5A
2 Module Battery By-pass (DC 48V,48AH or lower), 15.0A
Integration of Modules
Modules may share load among them and module swapping is also possible.
To Next Page
