OfficeServ 7200-S INSTALLATION
TECHNICAL MANUAL PART 3 MAY 2010
3.14
**TEPRI: Do not change the settings of DIP switches 3, 5, 6, 7, and 8. Switches 3, 5, 6, and 7
must remain OFF and 8 must be ON.
TEPRIa: Do not change the settings of DIP switch 3.
***The new TEPRIa and TEPRI2 cards have only a four position switch. Set the switches the
same as the eight positions using the same first four switches.
See the switch and jumpers of the TEPRI board as shown on the next page.
Figure 3.16 Setting Switches on the TEPRI Board
SW1
SW8
Off
On
JP7
J2
1
J1
1
JP6
1
1
JP9
JP8
1
1
1
1
JP5
JP3
JP4
1
S1
OFF
ON
SW 1 E1* T1*
SW 2 T1/E1* PRI
SW 3
24B+D
24B
SW 4
User
Network
SW 5
Non-used
AFT
(Automatic)
SW 6 Non-used Non-used
SW 7 Non-used Non-used
SW 8
17H
13H
