OfficeServ 7200-S INSTALLATION
TECHNICAL MANUAL PART 3 MAY 2010
3.27
The following chart provides current ratings for various devices connected to the system.
Card Name
Connected
Device Type
Current Consumption
per Each Device (mA)
DLI Digital Keyset 25
MWSLI
Analog Phone 25
Analog Phone with Message Waiting
Lamp
30
PLIM/PLIM2
(48 V)
ITP-5121D or ITP-5107S 100
ITP-5112L 130
SMT-R2000 Dual AP 200
SMT-i3105 83
SMT-i5210 127
SMT-i5220, SMT-i5230 107
SMT-i5243 156
SMT-i5264 100
A52GE Gigabit 56
Other IEEE 802.3af compliant device. See manufacture current draw specifications
IF ADDING PLIM/PLIM2 CONNECTED DEVICES CAUSES THE TOTAL CURRENT DRAWN TO
EXCEED 2200mA PER CABINET (not per system), THEN YOU MUST CONNECT THE OS7150
EXTERNAL PoE POWER SUPPLY MODULE to the cabinet. This unit will provide additional
power only to devices connected to PLIM/PLIM2s, when the OS7200 power supply limits have
been exceeded. Please refer to Section 5.3, CONNECTING THE OS7150 EXTERNAL PoE PSU
SUPPLEMENTAL POWER SUPPLY for further information.
Refer to the OfficeServ 7200-S Data Server Manual for detailed PLIM installation and
configuration information.
It is important to note that the OS7150 only provides additional power to the PLIM/PLIM2.
The OS7150 is used when the PLIM/PLIM2 connected devices causes the total current draw
per cabinet to exceed 2200mA. It does not
provide power to DLI and MWSLI ports.
SPECIFICATIONS
The PLIM data board provides 16 ports of 10/100 Base-T.
