4th Edition of TEMI880 IM : Jan. 29. 2007 Page 30 / 119
2.6.4 Fix Run Screen
Figure 2-14. Fix Run – First Screen Figure 2-15. Fix Run – Second Screen
No. Contents Description Additional Description
○
1
Temp. Tuning Temp. side : Auto Tuning On/Off.
▶ T-AT button’s color transferred to
red at Auto Tuning of the Temp. side.
○
2
Humi. Tuning Humi. side : Auto Tuning On/Off.
▶ H-AT button’s color transferred to
red at Auto Tuning of the Humi. side.
○
3
PID Group No. Display PID Group No. ▶ See 2.12.4 PID Setting Screen
○
4
Next Button Transfer at Figure 2-9.
○
3
○
1
○
2
○
4
