4th Edition of TEMI880 IM : Jan. 29. 2007 Page 79 / 119
Simple Example
The Example of the Pattern, Inner Signal and Time Signal Setting.
1 Seg
2 Seg 3 Seg 4 Seg 5 Seg 6 Seg 7 Seg
30 min 40 min 30 min 40 min 30 min 40 min 30 min
Humi. SP
Temp. SP
Inner Signal1
(IS1)
Inner Signal2
(IS2)
Time Signal1
(TS1)
Time Signal2
(TS2)
100.0℃
90.0℃
80.0℃
70.0℃
60.0℃
50.0℃
40.0℃
30.0℃
20.0℃
10.0℃
0.0℃
100.0%
90.0%
80.0%
70.0%
60.0%
50.0%
40.0%
30.0%
20.0%
10.0%
0.0%
