Installation and Operation Manual
Single frequency display shows the fish finder record
of 200KHz frequency.
High Frequency (200 kHz)
The 200 kHz frequency is ideal provide a better
resolution which means it is ideal for the observation
of fish or fish schools.
You can also review old sonar records, press
and
to review the history. To return to current
scanning, press
.
3-4-8 Split zoom and Full Screen zoom
Split zoom
Split zoom mode expands selected area of
the single frequency by VRM(Variable Range
Mark). The left side displays zoomed section
of current sonar record. The VRM of right
side indicates the zoom section area.
• Press or to change the zoom
range.
• Press
or
to change the depth
range.
Full Screen zoom
Full screen zoom displays only the zoom
section of split zoom.
[Split zoom] [Full screen zoom]
