5-2 Connections
Fishfinder has connectors that are used to connect to the power supply and to NMEA devices
such as AIS receivers, Autopilots and digital equipment.
5-3 Power / Data Cable
Power
• Connect each equipment as the below picture for Power.
Power / Data Cable
FUSE 2A
PIN No.1
PIN No.5
