Samyung F430 - Introduction; General Information; Product Specification

Installation and Operation Manual
7
1-1 General Information
Some functions require optional units and
sensors installed on your boat.
Fishfinder can be connected to external
devices and display information.
Following are the examples.
• NAVTEX
• AIS receiver
• DSC VHF radio
• Transducer & sensors
• Autopilot
1-2 Specification
[F430]
GENERAL
Category
Detail
Size
192.1 mm(H) x 108 mm(W) x 98.8 mm(D)
Display
4.3 “Diagonal, TFT color, 272 x 480 pixels
Supply Voltage
10 ~ 35 V DC
Supply Current
F 430
13.8 V
270 mA – LCD no Backlighting
400 mA – LCD full backlighting
Operating temperature
-10° ~ 50°C
ALARMS
User setting: Fish, Deep, Shallow, Temperature, Temperature rate, Low battery, AIS
Fishfinder
COMMUNICATIONS
NMEA
NMEA 0183 baud : 4800, 9600, 38400
NMEA 0183 Inputs
DBK, DBS, DBT, DPT, GGA, GLL, GNS, GGA, GSV, HDG, HDT, MDA,
MTA, MTW, MWD, M V, RMC, RPM, VHW, VTG, VWT, ZDA
NMEA 0183 Outputs
APA, APB, BWR, GGA, GLL, GSA, GSV, RMB, RMC, VTG, XTE, XDR,
ZDA, PLT
1 Introduction
