Sandel ST3400 - Page 111

A
A
B
B
C
C
D
D
E
E
4 4
3 3
2 2
1 1
Title
Size Document Number Rev
Create: Sheet of
Category
Mod:Monday, July 02, 2001
82002-10
F
OAT
SANDEL
Vista, Ca.
B
18
ST3400 INSTALLATION DRAWING
Thursday, July 28, 2016
Title
Size Document Number Rev
Create: Sheet of
Category
Mod:Monday, July 02, 2001
82002-10
F
OAT
SANDEL
Vista, Ca.
B
18
ST3400 INSTALLATION DRAWING
Thursday, July 28, 2016
Title
Size Document Number Rev
Create: Sheet of
Category
Mod:Monday, July 02, 2001
82002-10
F
OAT
SANDEL
Vista, Ca.
B
18
ST3400 INSTALLATION DRAWING
Thursday, July 28, 2016
COMMENTS
F
REV
04/14/03
DATE
A/R 626 INITIAL RELEASE
ST3400
J1 PRIMARY
SHIELD GROUND
OAT HI
29
1
CIC PN: 05257 PROBE
or Equivalent 500 Ohm
B
A
OAT PROBE
NOTE:
1. See Section 3 for OAT probe requirements.
(See Note 1)
COMPUTER CONTROLLED DRAWING
DO NOT REVISE MANUALLY
CIC PN: 05591 Connector
CIC PN: 05592 Mounting Plate
ST3400
J2 SECONDARY
AIRDATA RS232
OUTPUT
#2 AIRDATA RS232 IN HI
23
6
SHIELD GROUND
1
#2 AIRDATA RS232 IN LO 37
SOFTWARE
SELECT
SHADIN
ADC200
P2
6
SHADIN
ADC2000
P2
SHADIN C/D
SEE AIRINC AIRDATA PAGE FOR AIR
DATA COMPUTERS THAT SUPPLY ARINC
429 OAT LABEL
ARINC 429
SOFTWARE
SELECT
ST3400
J1 PRIMARY
23
SHIELD GROUND
#1 AIRDATA_429_AIN
#1 AIRDATA_429_BIN
37
1
ARINC 429 TX A
ARINC 429 TX B
2. If GPS receiver uses two RS232 ports, contact
Sandel before interfacing OAT using RS232
OAT PROBE
OAT RS232
OAT 429
