7 POST INSTALLATION
7.1 General
Post Installation testing and diagnostic procedures are accessed and addressed
through the Maintenance Interface.
7.1.1 Accessing Maintenance Pages
The Maintenance Interface allows the operator access to information pages.
The Maintenance Index page provides a menu that lists all accessible maintenance
pages. The maintenance index menu lists the number and title for each
maintenance page.
The Maintenance Interface can only be accessed during the system power-up
sequence. Before applying power to the system, the operator must press and hold
a combination of selection buttons. Exiting the maintenance pages completely
must be done via a power down / power up sequence.
The interface with the operator is in the read mode upon initial entry into the
maintenance pages. In the read mode all configuration values are read-only. To
make changes, the edit/read mode must be changed to edit.
7.1.1.1 Access the Maintenance Index page
Prior to applying power to the system:
Press and hold the
[BRG 1] [BRG 2] selection buttons until the Maintenance Index
page is displayed.
7.1.1.2 Quickly access a specific page
Press the [UP] Soft key or the [DOWN] Soft key to move the Cursor.
Press the button labeled
[SELECT] Soft key to display the page pointed to by the
Cursor.
or
Press Indicator or press the [PREV] soft key or the [NEXT] soft key.
7.1.1.3 Quickly return to the Maintenance Index page
Once any other maintenance page has been selected, for quick access to the
Maintenance Index page:
Press the [OPER] Soft key if with in the Maintenance pages or, press and hold the
[MAINT] Soft key if in the Flight Operation Display. Since these two soft keys are
the same physical button, this quick access sequence is done by pressing the
button twice.
7-16 ST3400 INSTALLATION MANUAL 82002-IM-L
