Sandel ST3400 - Post Installation Procedures

Recommended Crimp Tools
High Density
22-28 AWG
Standard Density
20-24 AWG
Hand
Crimping Tool Positioner
Insertion/
Extraction
Tool
Positioner
Insertion/
Extraction
Tool
Military P/N
M22520/2-01
M22520/2-09
M81969/1-04
M22520/2-08
M81969/1-02
Positronic
9507
9502-3
M81969/1-04
9502-5
M81969/1-02
ITT Cannon
995-0001-584
995-0001-739
N/A
995-0001-604
980-2000-426
AMP
601966-1
601966-6
91067-1
601966-5
91067-2
Daniels
AFM8
K42
M24308/18-1
K13-1
M24308/1-02
Astro
615717
615725
M81969/1-02
615724
M81969/1-02
2.6 Post Installation Procedures
Post installation procedures are summarized as follows:
1. Prior to power-up, review correct wiring by using industry accepted ohmmeter
and voltage checks. Pay particular attention to presence of +28V on only the
correct pins; 0 ohm resistance check on ground pins to airframe ground; and
presence of inverter 400Hz (if used) only on the appropriate pins.
2. Review any special items particular to the subject aircraft installation.
3. Power up the ST3400 in maintenance mode and sequentially access each
maintenance page to select the installed equipment.
4. Check proper cooling airflow:
A. Allow the unit to operate for 30 minutes.
B. Check the internal temperature readout on the appropriate maintenance
page for an approximate temperature rise (approximately 10°C or 18°F
over ambient).
5. Perform Ground Test procedures.
6. Perform Flight Test procedures if required.
82002-IM-L ST3400 INSTALLATION MANUAL
2-5
