11 APPENDIX B: ENVIRONMENTAL QUALIFICATION FORM
RTCA/D0-160D Environmental Qualification Form
NAMEPLATE NOMENCLATURE: [(A2)(F1)]ZBAB[(H)(R)]XXXXXXZBABB[WW]M[XXF2]XXA
TYPE/MODEL NO: ST3400 TSO NUMBERS: C151a, C92c, C113
MANUFACTURER’S SPECIFICATION AND/OR OTHER APPLICABLE SPECIFICATION:
a.) Design Requirements & Objectives For ST3400 TAWS, document number 82002-0010
b.) RTCA D0-160D Environmental Plan For Sandel ST3400 TAWS Class A/B, document number 82002-0090
MANUFACTURER: Sandel Avionics, Inc.
ADDRESS: 2401 Dogwood Way
Vista, CA 92083
REVISION & CHANGE NOS. OF D0-160: Revision D, Change
Nos. 1 & 2
DATE TESTED:
From: 1/31/02 To: 3/20/02
ENVIRONMENTAL
TESTS
RTCA/DO-
160D
SECTION
Equipment
Test
Category
Notes
Temperature & Altitude
Temperature Variation (combined):
Low Temperature
-Ground Survival
-Operational
High Temperature
-Ground Survival
-Operational
Altitude
-Decompression
-Overpressure
4.0
5.0
4.5.1
4.5.2 & 4.5.3
4.6
4.6.2
4.6.3
[(A2)(F1)B] PASS
In-Flight Loss of Cooling
4.5.4
[(A2)Z]
PASS
Humidity
6.0
A
PASS
Operational Shock and Crash Safety
7.0
B
PASS
Vibration 8.0 [(H)(R)] PASS:
RESONANT FREQUENCIES:
Section 8.7.2, Step a. and d.:
Pre-Scan: X: 195Hz, Y: 500Hz, Z: 160Hz
Post-Scan: X: 195Hz, Y: 450Hz, Z: 150Hz
Section 8.8.1.3, Steps a. and e.:
Pre-Scan: X: 190Hz, Y: 425Hz, Z: 145Hz
Post-Scan: X: 190Hz, Y: 625Hz, Z: 145Hz
Section 8.8.1.3, Steps b. and d.:
Pre-Scan: X: 190Hz, Y: 390Hz, Z: 150Hz
Post-Scan: X: 190Hz, Y: 625Hz, Z: 150Hz
Explosion 9.0 X
Water-proofness 10.0 X
Fluids Susceptibility 11.0 X
Sand and Dust 12.0 X
Fungus 13.0 X
Salt Spray 14.0 X
Magnetic Effect
15.0
Z
PASS
Power Input
16.0
B
PASS
Voltage Spike
17.0
A
PASS
Audio Frequency Susceptibility
18.0
B
PASS
Induced Signal Susceptibility
19.0
B
PASS
Radio Frequency Susceptibility
20.0
[WW]
PASS
Radio Frequency Emission
21.0
M
PASS
Lightning Induced Transient Susceptibility
22.0
[XX(EF)2]
PASS
Lightning Direct Effects 23.0 X
Icing 24.0 X
Electrostatic Discharge
25.0
A
PASS
