4.5 Connector P1
For electrical characteristics, see the table in section 4.9 by referencing the signal
type indicated in italics. Signal types enclosed in parentheses indicate
functionality that is reserved.
Pin # Name Signal Type (dependent on maintenance page selection)
16
Inverter Exc.
In Note: May be same or different than P2-16 inverter source.
Inverter 26Vac Excitation for items on connector P1
1
Shield Gnd
31
FMS1A Primary
In
A429 A side 429
(RS422) + side 422
(RS232) Ground side
17
FMS1B Primary
In
A429 B side 429
(RS422) - side 422
(RS232) Rx
2
Radalt1A
In
A429 A side 429
RadAlt Analog DC+ [ALT 50/55, ARINC 552, RT220/300, RT200]
32
Radalt1B
In
A429 B side (429)
RadAlt Analog DC- [ALT 50/55, ARINC 552, RT220/300, RT200]
18
Radalt1 Valid
In
Discrete Valid Discrete, Note: Not used when 429 is data source
3
Hdg1A
In
A429 A side 429
A407 Synchro X [Z grounded]
33
Hdg1B
In
A429 B side 429
A407 Synchro Y [Z grounded]
19
Hdg1 Valid
In
Discrete Valid Hdg Analog, Note: Not used when 429 is data source.
4
ADF1A
In
A429 A side 429
DC Sin DC Sine
A407 Synchro X [Z grounded]
34
ADF1B
In
A429 B side 429
DC Cos DC Cosine
A407 Synchro Y [Z grounded]
20
ADF1 DC Ref
In
ADF Ref ADF DC, Note: Not used when 429 or XYZ is data source.
5
ADF1 Valid
In
Discrete Valid ADF Discrete, Note: Not used when 429 is data source
35
Nav1A
In Note: For composite inputs see P2-42
A429 A side 429
(RS422) + side 422
(RS232) Ground side
21
Nav1B
In Note: For composite inputs see P2-42
A429 B side 429
(RS422) - side 422
(RS232) Rx
