s30nmdl2sm-REV0808 Model S30 Non-Metallic Page 31
Dual Port Option Drawing
3" ANSI STYLE FLANGE CONNECTION
FOUR ø.75 HOLES ON A ø6.00 BOLT CIRCLE
3" ANSI STYLE FLANGE CONNECTION
FOUR ø.75 HOLES ON A ø6.00 BOLT CIRCLE
