Page #4 background imageLoading...
Page #4 background image
s30nmdl2sm-REV0808 Model S30 Non-Metallic Page 2
Pump Brand
S= SANDPIPER
®
Pump Size
30=3"
Check Valve Type
B= Ball
Design Level
2= Design Level 2
Wetted Material
K= PVDF
P= Polypropylene
Diaphragm Check Valve Materials
1= Santoprene/Santoprene
2= PTFE-Santoprene Backup/PTFE
3= PTFE Pumping, PTFE-Santoprene
Backup Driver/PTFE
4= Santoprene Pumping, Santoprene
Driver/Santoprene
Check Valve Seat
K= PVDF
P= Polypropylene
U= Polyurethane/ Polyurethane
Non-Wetted Material Options
A= Painted Aluminum
J= Painted Aluminum PTFE
Q= Epoxy Coated Aluminum
K= PTFE Coated Aluminum
L= PTFE Coated Aluminum with
PTFE Coated Hardware
R= Epoxy Coated Aluminum with
PTFE Coated Hardware
Porting Options
A= ANSI Flange
D= DIN Flange
7= Dual Porting (ANSI)
8= Top Dual Porting (ANSI)
9= Bottom Dual Porting (ANSI)
Pump Style
D= Spill Containment with
Electronic Leak Detection (110V)
E= Spill Containment with
Electronic Leak Detection (220V)
M=Spill Containment with
Mechanical Leak Detection
S= Standard
V= Spill Containment with
Visual Leak Detection
Pump Options
0= None
1= Sound Dampening Muffl er
2= Mesh Muffl er
3= High temperature Air
Valve w/Integral Muffl er
4= High temperature
Air Valve with Sound
Dampening Muffl er
5= High temperature
Air Valve w/Mesh Muffl er
S30 Non-Metallic · Design Level 2· Ball Valve
Explanation of Pump Nomenclature
Kit Options
00.= None
P0.= 10-30VDC Pulse Output Kit
P1.= Intrinsically-Safe 5-30VDC,110/120VAC,
220/240VAC Pulse Output Kit
P2.= 110/120 or 220/240VAC
Pulse Output Kit
E0.= Solenoid Kit with 24VDC Coil
E1.= Solenoid Kit with 24VDC
Explosion-Proof Coil
E2.= Solenoid Kit with 24VAC/12VDC Coil
E3.= Solenoid Kit with12VDC
Explosion-Proof Coil
E4.= Solenoid Kit with 110VAC Coil
E5.= Solenoid Kit with 110VAC,
60 Hz Explosion-Proof Coil
E6.= Solenoid Kit with 220VAC Coil
E7.= Solenoid Kit with 220VAC,
60 Hz Explosion-Proof Coil
E8.= Solenoid Kit with 110VAC,
50 Hz Explosion-Proof Coil
E9.= Solenoid Kit with 230VAC,
50 Hz Explosion-Proof Coil
SP.= Stroke Indicator Pins
Check Diaphragm/ Check Non-Wetted Shipping
MODEL Pump Pump Valve Design Wetted Check Valve Valve Material Porting Pump Pump Kit Weight
Brand Size Type Level Material Materials Seat Options Options Style Options Options lbs. (kg)
S30B2P1PQAS000. S 30 B 2 P 1 P Q A S 0 00. 231 (105)
S30B2P2PQAS000. S 30 B 2 P 2 P Q A S 0 00. 231 (105)
S30B2K1KQAS000. S 30 B 2 K 1 K Q A S 0 00. 315 (143)
S30B2K2KQAS000. S 30 B 2 K 2 K Q A S 0 00. 315 (143)
S30B2P4PQAV000. S 30 B 2 P 4 P Q A V 0 00. 270 (122)
S30B2K4KQAV000. S 30 B 2 K 4 K Q A V 0 00. 354 (161)
