s30nmdl2sm-REV0808 Model S30 Non-Metallic Page 6
Dimensions: S30 Non-Metallic
with Spill Containment
Dimensions in Inches
Dimensional tolerance: ±
1
/
8"
Dimension
Standard Pump
A
B
6 9/16"
6 9/16"
Pulse Output Kit
Sound Dampening Muffl er
Mesh Muffl er
12 11/16"
12 11/16"
13 3/4"
22 9/32"
8 13/16"
14 15/16"
Note: Porting Flanges are also available with
PN10 40mm DIN bolting confi guration.
Note: Dimensions "B" is from
the opposite side of the pump
to the end of the muffl er.
Note: Dimensions "A" is from
the vertical center line to the
end of the muffl er.
