s30nmdl2sm-REV0808 Model S30 Non-Metallic Page 32
DUAL PORTING OPTIONS
Several dual porting options are
possible. The pump can be converted
to a dual port arrangement on both
the suction and the discharge ends.
The porting can be confi gured to a
single suction and a dual discharge.
The porting can be changed to a dual
suction and a single discharge.
The above changes are possible
because the porting flange of the
elbows (items 19) are designed to mate
with standard 125# ANSI style 4-bolt,
3" pipe fl anges.
Dual porting of both suction and
discharge ends of the pump
Converting the pump from the
standard single suction and discharge
porting confi guration to dual porting at
each end is easy. Simply remove the
manifold seals, spacers, and manifolds
(items 36, 39, and 24 from pump
assembly drawing) from the pump.
The discharge and suction elbows
can be rotated at 90° increments (see
arrows and optional positioning in the
Dual Porting Drawing.
Single porting of the suction and
dual porting of the pump discharge
To convert the pump from the
standard single suction and single
discharge porting confi guration to a dual
discharge porting arrangement remove
the only the discharge manifolds,
spacers, and manifold seals. Position
the discharge elbows in the desired
direction at 90° increments. (See arrows
and optional positioning in the Dual
Porting Drawing.)
Dual porting of the suction and single
porting of the pump discharge
To convert the pump from the
standard single suction and single
discharge porting confi guration to a dual
suction porting arrangement remove
the only the suction (bottom) manifolds,
spacers, and manifold seals.
Position the suction elbows in the
desired direction at 90° increments.
(See arrows and optional positioning
in the Dual Porting Drawing.)
Read these instructions
c o m p l e t e l y, b e f o r e
installation and start-up.
It is the responsibility of
the purchaser to retain
this manual for reference. Failure to comply
with the recommendations stated in this
manual will damage the pump, and void
factory warranty.
IMPORTANT
