GB-40
Preparation Connections Initial Setup Using the Features Using the Features
via USB port
Hints and Tips, Specification
and Safety Warnings
Specification
Model S40LDIB10 S46LDIB10
Panel System 40 inch LCD panel 46 inch LCD Panel
Display Resolution
1920 pixels (horizontal) x
1080 pixels (vertical)
1920 pixels (horizontal) x
1080 pixels (vertical)
Television System PAL I/BG/DK, SECAM L/BG/DK PAL I/BG/DK SEACAM L/BG/DK
Brightness 450 cd/m
2
450 cd/m
2
Contrast Ratio 5000 : 1 5000:1
Inputs/Output
SCART 1 1
HDMI 4 4
VGA 1 1
PC/DVI AUDIO 1 1
YPbPr 1 1
COMMON INTERFACE 1 1
USB 1 1
VIDEO IN (RCA) 1 1
AUDIO IN (RCA) 1 (L + R) 1 (L + R)
AERIAL 1 1
Speaker Power 9 W + 9 W 9 W + 9 W
Head phone (3.5mm) 1 1
Optical Audio Output 1 1
Power Source 220V-240V~50/60Hz 220V-240V~50/60Hz
Dimension( W x D x H) with base 989 x 260 x 689 mm 1127 x 285 x 770 mm
Weight (Net) 19.5 kg 24.3kg
Features and Specifications are subject to change without notice.
