GB-5
PreparationConnectionsInitial SetupUsing the FeaturesUsing the Features
via USB port
Hints and Tips, Specification
and Safety Warnings
Front View and Controls
Item Description
1 IR (Infrared Receiver)
Receives IR signals from the remote control.
Do not put anything near the sensor, as its function may be affected.
2 POWER LED
Illuminates red when the TV is in standby mode and flashes for a few seconds when
you turn on the TV. The LED will then remain steady red whilst the TV is switched on.
3 I/O POWER ON/OFF Switch on the I/O POWER ON/OFF switch to turn the TV to standby mode.
4 Touch Control Panel
Touch the touch control panel once to activate it (indicators on the touch control
panel will illuminate), and then press the touch sensitive controls to execute. The touch
control panel will automatically deactivated if untouched for several seconds.
a MENU Displays the OSD (on screen display) menu.
b SOURCE Select among the different input signal sources:
DTV / TV / SCART / AV / Component / VGA / HDMI1 / HDMI2 / HDMI3 / HDMI4 / DMP
c VOL
Adjust the volume.
Select and adjust a setting in the OSD menus.
d CH
Select a channel.
Select a sub-menu of the OSD menu.
e
Switch the TV on from standby.
Switch the TV back to standby.
1 2
3
a
c
d
e
b
