Santerno SINUS MINI Series - Page 33

SINUS MINI High performance Vector Control Inverter User Manual
32
F5.02
ASR proportional
gain 2
0.000~6.000
1.000
+
F5.03
ASR integration
time 2
0.000~9.999
1.000
+
F5.04
ASR switching
frequency
00.00~99.99Hz
5.00
+
F5.05
Slip compensation
gain
50.0~200.0%
100.0
+
F5.06
Driving torque limit
0~200.0%(motor rated current)
150.0
+
F5.07
Braking torque limit
0~200.0%(motor rated current)
150.0
+
F5.08
Reserved
Reserved
+
F5.09
Reserved
Reserved
+
F5.10
Reserved
Reserved
+
F6.00
FWD/REV mode
0: Two-line operation mode 1
1: Two-line operation mode 2
2: 3-line operation mode 1
3: 3-line operation mode 2
0
+
F6.01
Up/down rate
0.10~99.99Hz/s
1.00
#
F6.02
Definition of input
terminal X1
0 :No function
1: FWD
2: REV
3: External reset
4: Jog FWD
5: Jog REV
6: Multi-frequency 1
7: Multi-frequency 2
8: Multi-frequency 3
9: Multi-frequency 4
10: Terminals for selecting Acc/Dec time 1
11: Terminals for selecting Acc/Dec time 2
1
+
F6.03
Definition of input
terminal X2
2
+
F6.04
Definition of input
terminal X3
3
+
F6.05
Definition of input
terminal X4
4
+
F6.06
Definition of input
terminal X5
5
+
