SINUS MINI High performance Vector Control Inverter User Manual
34
F6.09
Programmable
relay 1
0: No function
1: Drive ready
2: Drive running signal 1
3: Drive running signal 2
4: Frequency arriving signal
5: Frequency detection threshold 1
6: Frequency detection threshold 2
7: High limit frequency arriving
8: Low limit frequency arriving
9: Overload signal
10: Over voltage stall
11: Over current stall
12: External stopping command
13: Preset counting value arriving
14: Specified counting value arriving
15: Low voltage lockup signal
16: Overload pre-alarm
17: Drive failure signal
18: Zero speed running
19：End signal of stage of program operation
20：End signal of cycle of program operation
17
+
F6.10
Output terminal Y1
definition
1
+
F6.11
Frequency arriving
width
0.00~10.00Hz
0.00
#
F6.12
FDT1 level
0.00~600.0 Hz
50.00
#
F6.13
FDT1 lag
0.00~10.00Hz
0.00
#
F6.14
FDT2 level
0.00~600.0 Hz
25.00
#
F6.15
FDT2 lag
0.00~10.00Hz
0.00
#
F6.16
Preset value
arriving
0~9999
0
+
F6.17
Specified value
arriving
0~9999
0
+
