【5】機能説明
DESCRIPUTION OF FUNCTIONS
5 - 1 つまみ・調整器

 



 

 



5
- 2 スタンドの使い方
リヤケース側にあるスタンドを図のようにして立ててご使用くだ
さい。
5-1 Knob and Adjuster
○Range selector knob
Turn this switch to turn on select the function and ranges.
○Zero position adjuster
This adjuter knob is turn and meter pointer is adjusted to 0 point
（scale left edge）.
○0 Ω・ Adjuster knob
It is used at the time of a resistance and ±DCV measurement.
・They short test pin at the time of Ω and this knob is turn and
pointer is adjusted to right edge（Ω scale of 0 place）of a scale.
Since pointer move automatically at the time of ±DCV, this
knob is turn and pointer is adjusted to center （ ± DCV scale of
0 place）of a scale.
5-2 How to Use the Stand
Please use the stand that there is on the side of rear case like a figure.
