6-6 抵抗（Ω）測定 最大測定抵抗2 MΩ
警 告
6-6 Resistance Measurement
Never apply voltage to the input terminals.
WARNING
1）Application
Resistance of resistors and circuits are measured.
2）Measuring ranges
×1/×10/×1 k（3ranges）
3）Measurement procedure
①Connect the black plug of the test lead to the −input
terminal and the red plug to the +input terminal.
②Set the range selector knob to an appropriate Ω range.
③Short the red and black test pins and turn the 0 Ω adjuster
so that the pointer may align exactly to 0 Ω.
④Apply the black and red test pin to the measured resistance.
⑤Read the move of the pointer by Ω scale.
⑥After measurement, remove the red and black test pins from
the resistor measured.
