Sanwa SP21 - 3】各部の名称; 3】Name of Component Units


DRAWING No SP21 18-1805 2040 2040
【3】各部の名称
NAME OF COMPONENT UNITS

Scale

Pointer

Zero position adjuster

Range selector knob

Meter cover

Panel


0 
adjuster knob

input terminal

input terminal
テストリード（TL-21a）
Test lead

T
est pins

Finger
guards

Plugs

Test probe (red)

Test probe (black)


Re
movable
test pin co
vers

When not covered
・着脱式テストピンキャップ装着時：CAT.III600V
・着脱式テストピンキャップ未装着時：CAT.II1000V
・When the removable test pin covers are mounted : CAT.III 600 V
・
When the removable test pin covers are not mounted: CAT.II 1000 V
