Sanwa SP21 - 6−4−2 直流電圧 （±DCV; DCV Measurement（±DCV


DRAWING No SP21 18-1805 2040 2040
6-4-2 直流電圧（±DCV ） 最大測定電圧 ±DC 30 V、6 V





󰴤

󰴥 

󰴦

󰴧

󰴨
󰴩
6-4-2
DCV MeasurementMaximum rating input value 30 V, 6 VDC
1Applications
Direct current power supply circuit check of the equipment
which uses IC.
2Measuring ranges
6/30（2ranges）
3Measurement procedure
󰴤Connect the black plug of the test lead to the − input
terminal and the red plug to the +input terminal.
󰴥Set the range selector knob to an appropriate DCV range.
󰴦Turn the 0 adjuster so that the pointer may align
exactly to 0 by DCV scale.
󰴧Apply the black test pin to the negative potential side of the
circuit to measure and the red test pin to the positive potential
side.
󰴨Read the move of the pointer by DCV scale.
󰴩After measurement, remove the red and black test pins from
the circuit measured.
