6-9 静電容量（μF）測定
警 告
6-9 Measuring Capacity（μF）
1.Never apply voltage to the input terminals.
2.Do not measure as for a condenser of a charged condition.
WARNING
1）Application
Measured large capacitor.
2）Measuring ranges
μF×1（same as Ω×1 k range）
3）Measurement procedure
①Connect the black plug of the test lead to the −input
terminal and the red plug to the +input terminal.
②Set the range selector knob to an appropriate μF×1 range.
③Short the red and black test pins and turn the 0 Ω adjuster
so that the pointer may align exactly to 0 Ω.
To Next Page
