6-10
別売直流高圧プローブ（HV-20）による測定 最大測定電圧DC 30 kV
警 告
6-10 DC High Voltage measurementOputinal HV Probe
1. The probe is designed for the measurement of very small
direct current circuit. Never use the probe to measure high
voltage in power lines, such as transmission and distribution
lines；it is very dangerous.
2. Never apply an input signals exceeding the maximum
measuring voltage（30 kV）of HV prove.
3. Be sure to disconnect the test pins from the circuit when
changing the function.
4. Always keep your fingers behind the finger guards on the
probe when making measurements.
WARNING
1）Applications
The probe is a suitable for measuring voltage of high
impedance circuits, such as CRT anode voltage of TV sets and
high voltage for focusing.
2）Measuring ranges
HV PROBE（DC 0.3 V）
