③Apply the black test pin to the negative potential side of the
circuit to measure and the red test pin to the positive
potential side.
④Read the move of the pointer by or V・A scale.
⑤After measurement, remove the red and black test pins from
the battery measured.
● range：20 Ω load
For measure the cylindrical type battery（R20, R14, R6P, LR20,
LR14, LR6 etc.）
● range：60 kΩ load
For measure the button type battery（SR43, SR44 etc.）
1.5V
1.5V
1.5V
1.5V
1.5V
1.5V
1.5V
Battery
