-34-
Electrical Adjustments
No. Adjustment Item Range
Initial Value
Description
54 PIXEL GAIN B 192 0 ~ 255
55 Not Used
56 Not Used
57 Not Used
58 Not Used
59 Not Used
60 Not Used
61 Not Used
62 Not Used
63 Not Used
NTSC PAL
64 AV Total-Dots 2015 2078 0 ~ 4096
65 AV Display-Dots 788 788
66 AV H Back-Porch 177 204
67 AV V Back-Porch 22 30
68 AV Normal Disp-Line 457 537
69 AV Clamp 100 100 1 ~ 255 Only HDTV
70 Not Used
71 Not Used
72 Not Used
73 Not Used
SVGA Initial Value
COMPUTER MCI VIDEO
74 Gamma RB1G 20 24
75 Gamma GB1G 20 24
76 Gamma BB1G 20 24
77 White Uniformity Compensation-V Area ✻ 0 0 ~ 12 Vertical area no. selection ✻ WHITE UNIFORMITYADJ.
78 White Uniformity Compensation-H Area ✻ 0 0 ~ 15 Horizontal area no. selection ✻ WHITE UNIFORMITY ADJ.
79 White Uniformity Compensation-Red ✻ 32 0 ~ 63 Red white balance adjustment ✻ WHITE UNIFORMITY ADJ.
80 White Uniformity Compensation-Green ✻ 32 0 ~ 63 Green white balance adjustment ✻ WHITE UNIFORMITY ADJ.
81 White Uniformity Compensation-Blue ✻ 32 0 ~ 63 Blue white balance adjustment ✻ WHITE UNIFORMITYADJ.
82 White Uniformity Compensation-Data Reset ✻ 0 0 ~ 10 Data Reset for White Uniformity Compensation
83 White Uniformity Compensation-On/Off ✻ 186 58 or 186 White uniformity compensation mode On/Off 58 : OFF, 186 : ON
To Next Page
