Projector Type Multi-media Projector
Dimensions (W x H x D) 239mm x 90mm x 323mm
Net Weight 3.9kg
LCD Panel System 0.9” TFT Active Matrix type, 3 panels
Panel Resolution 800 x 600 dots
Number of Pixels 1,440,000 (800 x 600 x 3 panels)
Color System 6 color system (PAL, SECAM, NTSC, NTSC4.43, PAL-M and PAL-N)
Scanning Frequency H-sync. 15 ~ 80kHz, V-sync. 50 ~ 100Hz
Projection Image Size (diagonal) Adjustable from 30” to 300”
Horizontal Resolution 750 TV lines
Projection Lens F1.7 ~ 2.0 lens with f33.2mm ~ 43.1mm Motor zoom and focus
Throw Distance 1.4m ~ 10.8m
Projection Lamp 150watt type
AV Input Jacks RCA Type x 1 (Video, Audio R and L) and DIN 4 pin (S-Video) x 1
Computer Input Jack (VGA) HDB15 Terminal x 1
Control Port Jack DIN 8 pin x 1
Monitor Output Jack (VGA) HDB15 Terminal x 1
Computer Audio Input Jack Mini Jack (stereo)
Audio Output Jack Mini Jack (stereo)
Internal Audio Amp. 1W RMS (monaural)
Built-in Speaker 1 speaker, 40mm x 30mm
Feet Adjustment 0˚ to 10˚
Voltage AC 200 ~ 240V, 50/60Hz
Power Consumption 1.4A (Max. Ampere)
Operating Temperature 5˚C ~ 35˚C
Storage Temperature -10˚C ~ 60˚C
Remote Control Transmitters Wireless Remote Control with Laser Beam (Class II Laser)
Max. Output 1mW/Wave length 650 ±20nm, batteries (2) AA type.
■ Specifications
● The specifications are subject to change without notice.
