Sanyo PLC-SU20E - Page 99

A11
(PLC-SU20E/SU22E/SU20B/SU22B)
RC Board (SIDE:A) RC Board (SIDE:B)Viewer Led Board (SIDE:A) Viewer Led Board (SIDE:B)
AV Board (SIDE:A)
AV Board (SIDE:B)
Key Board (SIDE:A)
Key Board (SIDE:B)
“K3001” “K3801”
AV Sub
Board
Main Comp.-A Board (SIDE:A) Main Comp.-A Board (SIDE:A)
Viewer Unit
“K3802” “K3002” “K15C” “K15F” “K15A”
AV Sub Board Main Comp.-B Board
Viewer
Unit
Main Comp.-D
Board “K2201”
