97
Using the real time capture
[4] Control by the computer with USB memory
The real time capture function can run automatically on the computer without the Network Viewer
& Capture 5 software installed by executing the Auto Capture program in the USB thumb drive
connected to the computer. The USB thumb drive for Auto Capture is supplied with this projector.
1. Turn on the projector and select “Network” from the input menu of the projector.
2. Select “LAN mode select” from the "Network" menu of the projector and press SELECT button. Select
"Wired 1/2/3 or “Wireless Simple” with the Point 54buttons.
( p.43)
3. Connect the above USB thumb drive, open it, and then double-click "MacAutoCap5".
4. Automatically, the activated executable file configures the Easy wireless setting. (If the network
adaptor selecting window appears, select an option according your network environment.) Then It
searches the projector, and starts the real time capture of the computer screen.
*The connection process of AutoCapture is different according to the equipped LAN adapter..
In case of only the wired LAN adapter is provided in the computer:
Connect to the network with the wired LAN adapter and search a projector.
In case of only the wireless LAN adapter is provided in the computer:
Change the LAN setting of the computer to SIMPLE and search a projector with the wireless LAN adapter.
In case of both the wired and wireless LAN adapters are provided in the computer:
When "Usually set it to a network adapter to use" is not checked; the network selection window is displayed.
5. For the following operations, refer to Page 94.
PC1
＊USB memory provides
Auto Capture program.
PC2
Project this screen
image with PJ1.
PJ1
* Start capturing of
the PC1.
Setting condition for automatically starting the real time capture function
Projector: Power: On, Input mode: Network, LAN mode select: Wired 1/2/3 or Wireless Simple
The searching result becomes only one projector.
Computer PC1: Log in by Administrative
The wireless LAN card or the Wired LAN card: Provided, Network Capture 5 software: NIL
Activate MacAutoCap5 in USB thumb drive
Before using wired LAN, the network settings should be completed.
If the error message appears, check item "Parameter set up" ( p.92).
When your computer provides multiple network adaptors, and "Select normal network adaptor" on the parameter
setup window is un-checked, the network adaptor selecting window ( p.24) will appear.
When plural projectors are found, the real-time capture will not start, but will become standby status. Release the
wireless LAN SIMPLE setting of the projector which is not for the real-time capture.
If the specified files are copied in the root of commercial USB memory, you can also perform the AutoCapture
( p.110).
