Sanyo PLV-Z3000 Service Manual

Electrical Parts List
ME4-Z300000
- 108 -
Key. No. Part No. Description
R9718 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R9719 401 351 1112 MT-GLAZE 51 DA 1/16W
R9721 401 351 1112 MT-GLAZE 51 DA 1/16W
R9722 401 351 1112 MT-GLAZE 51 DA 1/16W
R9723 401 351 1112 MT-GLAZE 51 DA 1/16W
R9724 401 351 1112 MT-GLAZE 51 DA 1/16W
R9726 401 351 1112 MT-GLAZE 51 DA 1/16W
R9727 401 351 1112 MT-GLAZE 51 DA 1/16W
R9728 401 351 1112 MT-GLAZE 51 DA 1/16W
R9729 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R9731 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R9732 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R9733 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R9734 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R9736 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
RB301 945 037 0671 R-NETWORK 47X4 0.063W
945 018 8931 R-NETWORK 47X4 1/16W
RB302 945 037 0671 R-NETWORK 47X4 0.063W
945 018 8931 R-NETWORK 47X4 1/16W
RB303 945 037 0671 R-NETWORK 47X4 0.063W
945 018 8931 R-NETWORK 47X4 1/16W
RB304 945 037 0671 R-NETWORK 47X4 0.063W
945 018 8931 R-NETWORK 47X4 1/16W
RB306 945 037 0671 R-NETWORK 47X4 0.063W
945 018 8931 R-NETWORK 47X4 1/16W
RB307 945 037 0671 R-NETWORK 47X4 0.063W
945 018 8931 R-NETWORK 47X4 1/16W
RB308 945 037 0671 R-NETWORK 47X4 0.063W
945 018 8931 R-NETWORK 47X4 1/16W
RB309 945 037 0671 R-NETWORK 47X4 0.063W
945 018 8931 R-NETWORK 47X4 1/16W
RB311 945 037 0671 R-NETWORK 47X4 0.063W
945 018 8931 R-NETWORK 47X4 1/16W
RB312 945 037 0671 R-NETWORK 47X4 0.063W
945 018 8931 R-NETWORK 47X4 1/16W
RB313 945 037 0671 R-NETWORK 47X4 0.063W
945 018 8931 R-NETWORK 47X4 1/16W
RB316 945 037 0671 R-NETWORK 47X4 0.063W
945 018 8931 R-NETWORK 47X4 1/16W
RB317 945 037 0671 R-NETWORK 47X4 0.063W
945 018 8931 R-NETWORK 47X4 1/16W
RB318 945 037 3108 R-NETWORK 10X4 0.063W
945 028 5982 R-NETWORK 10X4 1/16W
RB321 945 037 0671 R-NETWORK 47X4 0.063W
945 018 8931 R-NETWORK 47X4 1/16W
RB322 945 037 0671 R-NETWORK 47X4 0.063W
945 018 8931 R-NETWORK 47X4 1/16W
RB331 945 036 0986 R-NETWORK 47X4 1/32W
945 037 0831 R-NETWORK 47X4 1/16W
RB332 945 036 0986 R-NETWORK 47X4 1/32W
945 037 0831 R-NETWORK 47X4 1/16W
RB333 945 036 0986 R-NETWORK 47X4 1/32W
945 037 0831 R-NETWORK 47X4 1/16W
RB334 945 036 0986 R-NETWORK 47X4 1/32W
945 037 0831 R-NETWORK 47X4 1/16W
RB336 945 036 0986 R-NETWORK 47X4 1/32W
945 037 0831 R-NETWORK 47X4 1/16W
RB337 945 036 0986 R-NETWORK 47X4 1/32W
945 037 0831 R-NETWORK 47X4 1/16W
RB3401 645 058 6422 R-NETWORK 68X4 1/32W
945 054 1118 R-NETWORK 68X4 1/16W
RB3402 645 058 6422 R-NETWORK 68X4 1/32W
945 054 1118 R-NETWORK 68X4 1/16W
RB3403 645 058 6422 R-NETWORK 68X4 1/32W
945 054 1118 R-NETWORK 68X4 1/16W
RB3404 645 058 6422 R-NETWORK 68X4 1/32W
945 054 1118 R-NETWORK 68X4 1/16W
RB4401 945 036 3529 R-NETWORK 0X4 1/32W
945 037 0817 R-NETWORK 0X4 1/16W
RB4402 945 036 3529 R-NETWORK 0X4 1/32W
945 037 0817 R-NETWORK 0X4 1/16W
RB4403 945 036 3529 R-NETWORK 0X4 1/32W
945 037 0817 R-NETWORK 0X4 1/16W
RB4404 945 036 3529 R-NETWORK 0X4 1/32W
945 037 0817 R-NETWORK 0X4 1/16W
RB4406 945 036 3529 R-NETWORK 0X4 1/32W
945 037 0817 R-NETWORK 0X4 1/16W
RB4407 945 036 3529 R-NETWORK 0X4 1/32W
945 037 0817 R-NETWORK 0X4 1/16W
RB4801 945 037 0664 R-NETWORK 22X4 0.063W
945 021 4944 R-NETWORK 22X4 1/16W
RB5201 945 036 3529 R-NETWORK 0X4 1/32W
945 037 0817 R-NETWORK 0X4 1/16W
RB5202 945 036 3529 R-NETWORK 0X4 1/32W
945 037 0817 R-NETWORK 0X4 1/16W
RB5203 945 036 3529 R-NETWORK 0X4 1/32W
945 037 0817 R-NETWORK 0X4 1/16W
RB5204 945 036 3529 R-NETWORK 0X4 1/32W
945 037 0817 R-NETWORK 0X4 1/16W
RB5206 945 036 3529 R-NETWORK 0X4 1/32W
945 037 0817 R-NETWORK 0X4 1/16W
RB5207 945 036 3529 R-NETWORK 0X4 1/32W
945 037 0817 R-NETWORK 0X4 1/16W
RB5208 945 036 3529 R-NETWORK 0X4 1/32W
945 037 0817 R-NETWORK 0X4 1/16W
RB5209 945 036 3529 R-NETWORK 0X4 1/32W
945 037 0817 R-NETWORK 0X4 1/16W
RB5211 945 034 5051 R-NETWORK 22X4 1/32W
945 037 0824 R-NETWORK 22X4 1/16W
RB5212 945 034 5051 R-NETWORK 22X4 1/32W
945 037 0824 R-NETWORK 22X4 1/16W
RB5213 945 034 5051 R-NETWORK 22X4 1/32W
945 037 0824 R-NETWORK 22X4 1/16W
RB5214 945 034 5051 R-NETWORK 22X4 1/32W
945 037 0824 R-NETWORK 22X4 1/16W
RB5216 945 034 5051 R-NETWORK 22X4 1/32W
945 037 0824 R-NETWORK 22X4 1/16W
RB5217 945 034 5051 R-NETWORK 22X4 1/32W
945 037 0824 R-NETWORK 22X4 1/16W
RB5218 945 034 5051 R-NETWORK 22X4 1/32W
945 037 0824 R-NETWORK 22X4 1/16W
RB5219 945 034 5051 R-NETWORK 22X4 1/32W
945 037 0824 R-NETWORK 22X4 1/16W
RB5221 945 036 3529 R-NETWORK 0X4 1/32W
945 037 0817 R-NETWORK 0X4 1/16W
RB5222 945 036 3529 R-NETWORK 0X4 1/32W
945 037 0817 R-NETWORK 0X4 1/16W
RB5223 945 036 3529 R-NETWORK 0X4 1/32W
945 037 0817 R-NETWORK 0X4 1/16W
RB5224 945 034 5051 R-NETWORK 22X4 1/32W
945 037 0824 R-NETWORK 22X4 1/16W
RB5226 945 034 5051 R-NETWORK 22X4 1/32W
945 037 0824 R-NETWORK 22X4 1/16W
RB5227 945 034 5051 R-NETWORK 22X4 1/32W
945 037 0824 R-NETWORK 22X4 1/16W
RB5228 945 034 5051 R-NETWORK 22X4 1/32W
945 037 0824 R-NETWORK 22X4 1/16W
RB5231 645 093 1055 R-NETWORK 120X4 1/32W
645 093 0621 R-NETWORK 120X4 1/16W
RB5232 645 093 1055 R-NETWORK 120X4 1/32W
645 093 0621 R-NETWORK 120X4 1/16W
RB5233 645 093 1055 R-NETWORK 120X4 1/32W
645 093 0621 R-NETWORK 120X4 1/16W
RB5234 645 093 1055 R-NETWORK 120X4 1/32W
645 093 0621 R-NETWORK 120X4 1/16W
RB5236 645 093 1055 R-NETWORK 120X4 1/32W
645 093 0621 R-NETWORK 120X4 1/16W
RB5237 645 093 1055 R-NETWORK 120X4 1/32W
645 093 0621 R-NETWORK 120X4 1/16W
RB5241 645 093 1055 R-NETWORK 120X4 1/32W
645 093 0621 R-NETWORK 120X4 1/16W
RB5242 645 093 1055 R-NETWORK 120X4 1/32W
645 093 0621 R-NETWORK 120X4 1/16W
RB5243 645 093 1055 R-NETWORK 120X4 1/32W
645 093 0621 R-NETWORK 120X4 1/16W
RB5244 645 093 1055 R-NETWORK 120X4 1/32W
Key. No. Part No. Description

Sanyo PLV-Z3000 Specifications

General

Matrix size	0.7 \
Vertical scan range	50 - 100 Hz
Horizontal scan range	15 - 80 kHz
Projection technology	LCD
Contrast ratio (typical)	-
Screen size compatibility	40 - 300 \
Aspect ratio	16:9
RS-232 ports	1
Dimensions (WxDxH)	400 x 146 x 346 mm
Lamp type	UHP
Lamp power	165 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Focus	Manual
Focal length range	22.3 - 45.3 mm
Noise level	19 dB
Dot clock scanning frequency	100 MHz
Serial interface type	RS-232
Component video (YPbPr/YCbCr) in	3

Weight and Dimensions

Weight	7500 g
