Sanyo PLV-Z3000 Service Manual

Electrical Parts List
ME4-Z300000
- 94 -
Key. No. Part No. Description
ASSEMBLED BOARD
!
A8801 610 335 4651 ASSY,PWB,DOOR SWITCH1 MD4A
!
A8802 610 335 4699 ASSY,PWB,DOOR SWITCH2 MD4A
!
A8803 610 335 4668 ASSY,PWB,LAMP SWITCH MD4A
!
A601 610 341 4263 ASSY,PWB,FILTER MF4A
!
A100 610 341 2443 ASSY,PWB,MAIN.ME4A
!
A101 610 341 6113 ASSY,PWB,R/C.ME4A
!
A102 610 341 6120 ASSY,PWB,FILTER NET.ME4A
OUT OF CIRCUIT BOARD
L901 945 003 3811 CORE,FERRITE
945 040 2594 CORE,FERRITE
L902 945 003 3835 CORE,FERRITE
! LP901 610 344 5120 POA-LMP135
* 945 003 3835 CORE,FERRITE
! A901 645 093 7811 UNIT,BALLAST
! A902 645 098 0480 UNIT,POWER
! BLST&LMP 610 336 0157 CABLE,BALLAST MD4A
! FN901 645 098 4303 MOTOR,FAN DC ***W
! FN902 645 094 2686 MOTOR,BLW DC 4.14W
! FN903 645 098 4310 MOTOR,FAN DC ***W
! FN904 645 094 2693 MOTOR,BLW DC 4.14W
! FN905 645 098 0534 MOTOR,BLW DC 4.44W
! SW902 945 048 3159 SWITCH,THERMAL(100DEG)
! SW903 645 098 0701 SWITCH,DETECTOR 1P-2T
! TH901 945 079 7768 SWITCH,THERMAL,THERMISTOR
! TH902 945 079 7775 SWITCH,THERMAL,THERMISTOR
WK8J 610 341 3884 HALOGEN FREE WIRE 4P 1.5MM
WK8L 610 337 2198 HALOGEN FREE WIRE 3P 1.5MM BLU
WK8M 610 337 2181 HALOGEN FREE WIRE 3P 1.5MM RED
WK8P 610 337 2204 HALOGEN FREE WIRE 5P 1.5MM
WK8Q 610 337 2204 HALOGEN FREE WIRE 5P 1.5MM
WK8R 610 337 2204 HALOGEN FREE WIRE 5P 1.5MM
610 335 4651 ASSY,PWB,DOOR SWITCH1 MD4A
SW8801 945 056 0751 SWITCH,MICRO 1P-2T
610 335 4699 ASSY,PWB,DOOR SWITCH2 MD4A
SW8811 945 056 0751 SWITCH,MICRO 1P-2T
610 335 4668 ASSY,PWB,LAMP SWITCH MD4A
SW8803 945 063 5176 SWITCH,PUSH 2P-2TX3
610 341 4263 ASSY,PWB,FILTER MF4A
CAPACITOR
! C611 304 094 3801 MT-POLYEST 0.22U K 275V
! C612 304 094 3801 MT-POLYEST 0.22U K 275V
! C613 304 094 3801 MT-POLYEST 0.22U K 275V
! C614 304 073 4508 CERAMIC 2200P K 250V
304 071 4104 CERAMIC 2200P M 400V
! C616 304 073 4508 CERAMIC 2200P K 250V
304 071 4104 CERAMIC 2200P M 400V
RESISTOR
! R611 301 008 8620 CARBON 220K JA 1/2W
VARIABLE RESISTOR
! VA611 408 066 1700 VD TND14SE471KB0SLAA0
COIL
L611 945 050 2232 LINE FILTER
L612 945 050 2232 LINE FILTER
MISCELLANEOUS
! F601 323 024 3209 FUSE 250V 5A
! K601 645 093 1765 SOCKET,INLET AC 3P
! SW601 645 095 5808 SWITCH,POWER 2P-2TX2
610 341 2443 ASSY,PWB,MAIN.ME4A
TRANSISTOR
Q1001 305 217 8614 TR RN1105 TE85L
Q1003 305 217 8614 TR RN1105 TE85L
Q1004 305 217 8614 TR RN1105 TE85L
Q1006 305 217 8614 TR RN1105 TE85L
Q1051 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q1052 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q1053 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q1081 305 217 7518 TR RN1102 TE85L
Q1231 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q1243 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q1244 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q1246 305 134 5928 TR 2SA1037AK-T146-R
Q1248 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q1249 305 134 5928 TR 2SA1037AK-T146-R
Q1343 305 134 5928 TR 2SA1037AK-T146-R
Q2853 305 217 7518 TR RN1102 TE85L
Q2854 305 217 7518 TR RN1102 TE85L
Q2856 305 217 7518 TR RN1102 TE85L
Q2857 305 217 7518 TR RN1102 TE85L
Q3001 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q3002 305 014 4512 TR 2SC2412K T146 R
Key. No. Part No. Description

Sanyo PLV-Z3000 Specifications

General

Matrix size	0.7 \
Vertical scan range	50 - 100 Hz
Horizontal scan range	15 - 80 kHz
Projection technology	LCD
Contrast ratio (typical)	-
Screen size compatibility	40 - 300 \
Aspect ratio	16:9
RS-232 ports	1
Dimensions (WxDxH)	400 x 146 x 346 mm
Lamp type	UHP
Lamp power	165 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Focus	Manual
Focal length range	22.3 - 45.3 mm
Noise level	19 dB
Dot clock scanning frequency	100 MHz
Serial interface type	RS-232
Component video (YPbPr/YCbCr) in	3

Weight and Dimensions

Weight	7500 g
