Sanyo PLV-Z3000 Service Manual

Electrical Parts List
ME4-Z300000
- 110 -
Key. No. Part No. Description
L7861 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
L7871 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
L7872 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
L7873 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
L7874 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
L7876 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
L8001 945 086 6600 IMPEDANCE,220 OHM P
L8002 945 086 6600 IMPEDANCE,220 OHM P
L8003 945 086 6600 IMPEDANCE,220 OHM P
L8004 945 086 6600 IMPEDANCE,220 OHM P
L8006 945 086 6600 IMPEDANCE,220 OHM P
L8007 945 086 6600 IMPEDANCE,220 OHM P
L8081 945 086 6662 IMPEDANCE,600 OHM P
L8091 945 086 6600 IMPEDANCE,220 OHM P
L8821 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
L8822 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
L8823 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
L8831 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
L8832 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
L8833 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
L8851 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
L8852 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
L8853 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
L8854 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
L8871 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
L8872 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
L8873 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
DIODE
D1081 307 205 5216 DIODE RB521S-30-TE61
D1082 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
D1083 307 205 5216 DIODE RB521S-30-TE61
D2853 307 163 0414 DIODE 1SS352-(TPH3)
D2854 307 163 0414 DIODE 1SS352-(TPH3)
D2856 307 163 0414 DIODE 1SS352-(TPH3)
D2857 307 163 0414 DIODE 1SS352-(TPH3)
D2868 407 264 6312 LED SMLE12Y8W T86
D2869 407 264 6510 LED SMLE12V8W T86
D2871 307 222 4810 LED SML-521MUW T86
D4603 307 223 0712 ZENER DIODE 02DZ20Y(TPH3)
D4608 307 223 0712 ZENER DIODE 02DZ20Y(TPH3)
D5281 307 163 0414 DIODE 1SS352-(TPH3)
D5282 307 163 0414 DIODE 1SS352-(TPH3)
D5283 307 163 0414 DIODE 1SS352-(TPH3)
D5284 307 163 0414 DIODE 1SS352-(TPH3)
D5621 307 254 2914 ZENER DIODE 02DZ6.8Y(TPH3
D5661 307 254 2914 ZENER DIODE 02DZ6.8Y(TPH3
D5686 307 163 0414 DIODE 1SS352-(TPH3)
D5771 307 163 0414 DIODE 1SS352-(TPH3)
D5791 307 163 0414 DIODE 1SS352-(TPH3)
D6551 307 254 2914 ZENER DIODE 02DZ6.8Y(TPH3
D6552 307 163 0414 DIODE 1SS352-(TPH3)
D6553 307 163 0414 DIODE 1SS352-(TPH3)
D6562 307 163 0414 DIODE 1SS352-(TPH3)
D6563 307 163 0414 DIODE 1SS352-(TPH3)
D6671 307 163 0414 DIODE 1SS352-(TPH3)
D6681 307 254 2914 ZENER DIODE 02DZ6.8Y(TPH3
D6691 307 163 0414 DIODE 1SS352-(TPH3)
D6801 307 222 5916 ZENER DIODE UDZS3.6B-TE-17
D6811 307 222 5916 ZENER DIODE UDZS3.6B-TE-17
D6812 307 163 0414 DIODE 1SS352-(TPH3)
D6813 307 222 5916 ZENER DIODE UDZS3.6B-TE-17
D6821 307 222 5916 ZENER DIODE UDZS3.6B-TE-17
D6822 307 163 0414 DIODE 1SS352-(TPH3)
D6823 307 222 5916 ZENER DIODE UDZS3.6B-TE-17
D6831 307 222 5916 ZENER DIODE UDZS3.6B-TE-17
D6832 307 163 0414 DIODE 1SS352-(TPH3)
D6833 307 222 5916 ZENER DIODE UDZS3.6B-TE-17
D7601 307 163 0414 DIODE 1SS352-(TPH3)
D7621 307 163 0414 DIODE 1SS352-(TPH3)
D7821 307 254 2716 DIODE CMS16
D7831 307 254 2716 DIODE CMS16
D7841 307 254 2716 DIODE CMS16
D7851 307 254 2716 DIODE CMS16
D7871 307 163 0414 DIODE 1SS352-(TPH3)
D7872 307 163 0414 DIODE 1SS352-(TPH3)
D7873 307 163 0414 DIODE 1SS352-(TPH3)
D7874 307 163 0414 DIODE 1SS352-(TPH3)
D7876 307 163 0414 DIODE 1SS352-(TPH3)
D7877 307 163 0414 DIODE 1SS352-(TPH3)
D7878 307 163 0414 DIODE 1SS352-(TPH3)
D7879 307 163 0414 DIODE 1SS352-(TPH3)
D7881 307 163 0414 DIODE 1SS352-(TPH3)
D7882 307 163 0414 DIODE 1SS352-(TPH3)
D8081 307 254 2716 DIODE CMS16
D8082 307 163 0414 DIODE 1SS352-(TPH3)
D8091 307 254 2716 DIODE CMS16
D8092 307 163 0414 DIODE 1SS352-(TPH3)
D8821 307 223 0910 ZENER DIODE 02DZ4.7Y(TPH3
D8831 307 223 0910 ZENER DIODE 02DZ4.7Y(TPH3
D887 307 163 0414 DIODE 1SS352-(TPH3)
D888 307 163 0414 DIODE 1SS352-(TPH3)
MISCELLANEOUS
K10A 945 077 1058 SOCKET,IF(HDMI) 19P
K10B 945 077 1058 SOCKET,IF(HDMI) 19P
K10C 645 089 7696 SOCKET,D-SUB 15P
952 001 8601 SOCKET,D-SUB 15P
K10D 945 067 6124 TERMINAL,BOARD
K10E 945 071 9029 JACK,RCA-6
K10G 945 041 1077 SOCKET,DIN 8P
SC1001 945 076 3503 SURGE-ABSORBER
SC1004 945 076 3503 SURGE-ABSORBER
SC1021 945 076 3503 SURGE-ABSORBER
SC1024 945 076 3503 SURGE-ABSORBER
SC1051 945 076 3503 SURGE-ABSORBER
SC1052 945 076 3503 SURGE-ABSORBER
SC1053 945 076 3503 SURGE-ABSORBER
SC1054 945 076 3503 SURGE-ABSORBER
SC1056 945 076 3503 SURGE-ABSORBER
SC1057 945 076 3503 SURGE-ABSORBER
SC1058 945 076 3503 SURGE-ABSORBER
SC1059 945 076 3503 SURGE-ABSORBER
SC2001 945 076 3503 SURGE-ABSORBER
SC2002 945 076 3503 SURGE-ABSORBER
SC2851 945 076 3503 SURGE-ABSORBER
SC2852 945 076 3503 SURGE-ABSORBER
SC2853 945 076 3503 SURGE-ABSORBER
SC2854 945 076 3503 SURGE-ABSORBER
SC3001 945 076 3503 SURGE-ABSORBER
SC3002 945 076 3503 SURGE-ABSORBER
SC3003 945 076 3503 SURGE-ABSORBER
SC3004 945 076 3503 SURGE-ABSORBER
SC3006 945 076 3503 SURGE-ABSORBER
SC3007 945 076 3503 SURGE-ABSORBER
SC4001 945 076 3503 SURGE-ABSORBER
SC4021 945 076 3503 SURGE-ABSORBER
SC4041 945 076 3503 SURGE-ABSORBER
SC8851 945 076 3503 SURGE-ABSORBER
SC8852 945 076 3503 SURGE-ABSORBER
SC8871 945 076 3503 SURGE-ABSORBER
SC8872 945 076 3503 SURGE-ABSORBER
SW6801 945 026 2792 SWITCH,PUSH 1P-1TX1
SW6811 945 026 2792 SWITCH,PUSH 1P-1TX1
SW6812 945 026 2792 SWITCH,PUSH 1P-1TX1
SW6813 945 026 2792 SWITCH,PUSH 1P-1TX1
SW6821 945 026 2792 SWITCH,PUSH 1P-1TX1
SW6822 945 026 2792 SWITCH,PUSH 1P-1TX1
SW6823 945 026 2792 SWITCH,PUSH 1P-1TX1
SW6831 945 026 2792 SWITCH,PUSH 1P-1TX1
SW6832 945 026 2792 SWITCH,PUSH 1P-1TX1
X1351 945 088 7179 OSC,CRYSTAL 27.0MHZ
X5701 645 097 4793 OSC,CERAMIC 20MHZ
X7201 645 097 0238 OSC,CRYSTAL 33.3333MHZ
X7202 645 097 0238 OSC,CRYSTAL 33.3333MHZ
X8001 945 088 7179 OSC,CRYSTAL 27.0MHZ
Key. No. Part No. Description

Sanyo PLV-Z3000 Specifications

General

Matrix size	0.7 \
Vertical scan range	50 - 100 Hz
Horizontal scan range	15 - 80 kHz
Projection technology	LCD
Contrast ratio (typical)	-
Screen size compatibility	40 - 300 \
Aspect ratio	16:9
RS-232 ports	1
Dimensions (WxDxH)	400 x 146 x 346 mm
Lamp type	UHP
Lamp power	165 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Focus	Manual
Focal length range	22.3 - 45.3 mm
Noise level	19 dB
Dot clock scanning frequency	100 MHz
Serial interface type	RS-232
Component video (YPbPr/YCbCr) in	3

Weight and Dimensions

Weight	7500 g
