Sanyo PLV-Z3000 Service Manual

Electrical Parts List
ME4-Z300000
- 98 -
Key. No. Part No. Description
C411 303 369 0527 CERAMIC 0.01U K 25V
C412 303 369 0527 CERAMIC 0.01U K 25V
C413 303 369 0527 CERAMIC 0.01U K 25V
C414 303 369 0527 CERAMIC 0.01U K 25V
C416 303 369 0527 CERAMIC 0.01U K 25V
C417 303 369 0527 CERAMIC 0.01U K 25V
C418 303 369 0527 CERAMIC 0.01U K 25V
C419 303 369 0527 CERAMIC 0.01U K 25V
C421 303 369 0527 CERAMIC 0.01U K 25V
C422 303 369 0527 CERAMIC 0.01U K 25V
C423 303 369 0527 CERAMIC 0.01U K 25V
C424 303 369 0527 CERAMIC 0.01U K 25V
C426 303 369 0527 CERAMIC 0.01U K 25V
C427 303 369 0527 CERAMIC 0.01U K 25V
C428 303 369 0527 CERAMIC 0.01U K 25V
C429 303 369 0527 CERAMIC 0.01U K 25V
C431 303 369 0527 CERAMIC 0.01U K 25V
C432 303 369 0527 CERAMIC 0.01U K 25V
C433 303 369 0527 CERAMIC 0.01U K 25V
C434 303 369 0527 CERAMIC 0.01U K 25V
C436 303 369 0527 CERAMIC 0.01U K 25V
C437 303 369 0527 CERAMIC 0.01U K 25V
C438 303 369 0527 CERAMIC 0.01U K 25V
C439 303 369 0527 CERAMIC 0.01U K 25V
C4401 303 409 3426 CERAMIC 0.1U K 16V
C4402 303 409 3426 CERAMIC 0.1U K 16V
C4403 303 409 3426 CERAMIC 0.1U K 16V
C4404 303 409 3426 CERAMIC 0.1U K 16V
C4406 303 409 3426 CERAMIC 0.1U K 16V
C4407 303 409 3426 CERAMIC 0.1U K 16V
C4408 303 409 3426 CERAMIC 0.1U K 16V
C4409 303 409 3426 CERAMIC 0.1U K 16V
C441 303 369 0527 CERAMIC 0.01U K 25V
C4411 303 409 3426 CERAMIC 0.1U K 16V
C4412 303 409 3426 CERAMIC 0.1U K 16V
C4413 303 409 3426 CERAMIC 0.1U K 16V
C4414 303 409 3426 CERAMIC 0.1U K 16V
C4416 303 409 3426 CERAMIC 0.1U K 16V
C4417 303 409 3426 CERAMIC 0.1U K 16V
C4418 303 409 3426 CERAMIC 0.1U K 16V
C4419 303 409 3426 CERAMIC 0.1U K 16V
C442 303 369 0527 CERAMIC 0.01U K 25V
C4421 303 409 3426 CERAMIC 0.1U K 16V
C4422 303 409 3426 CERAMIC 0.1U K 16V
C4423 303 409 3426 CERAMIC 0.1U K 16V
C4424 303 409 3426 CERAMIC 0.1U K 16V
C4426 303 409 3426 CERAMIC 0.1U K 16V
C4427 303 409 3426 CERAMIC 0.1U K 16V
C4428 303 409 3426 CERAMIC 0.1U K 16V
C4429 303 409 3426 CERAMIC 0.1U K 16V
C443 303 369 0527 CERAMIC 0.01U K 25V
C4431 303 409 3426 CERAMIC 0.1U K 16V
C4432 303 409 3426 CERAMIC 0.1U K 16V
C4433 303 409 3426 CERAMIC 0.1U K 16V
C4434 303 409 3426 CERAMIC 0.1U K 16V
C4436 303 409 3426 CERAMIC 0.1U K 16V
C4437 303 409 3426 CERAMIC 0.1U K 16V
C4438 303 409 3426 CERAMIC 0.1U K 16V
C4439 303 409 3426 CERAMIC 0.1U K 16V
C444 303 369 0527 CERAMIC 0.01U K 25V
C4441 303 409 3426 CERAMIC 0.1U K 16V
C4442 303 409 3426 CERAMIC 0.1U K 16V
C4443 303 409 3426 CERAMIC 0.1U K 16V
C4444 303 409 3426 CERAMIC 0.1U K 16V
C4446 303 409 3426 CERAMIC 0.1U K 16V
C4447 303 409 3426 CERAMIC 0.1U K 16V
C4448 303 409 3426 CERAMIC 0.1U K 16V
C4449 303 409 3426 CERAMIC 0.1U K 16V
C4451 303 409 3426 CERAMIC 0.1U K 16V
C4452 303 409 3426 CERAMIC 0.1U K 16V
C4453 303 409 3426 CERAMIC 0.1U K 16V
C4454 303 409 3426 CERAMIC 0.1U K 16V
C4456 303 409 3426 CERAMIC 0.1U K 16V
C4457 303 409 3426 CERAMIC 0.1U K 16V
C4458 303 409 3426 CERAMIC 0.1U K 16V
C4459 303 409 3426 CERAMIC 0.1U K 16V
C446 303 369 0527 CERAMIC 0.01U K 25V
C4461 303 409 3426 CERAMIC 0.1U K 16V
C4462 303 409 3426 CERAMIC 0.1U K 16V
C4463 303 409 3426 CERAMIC 0.1U K 16V
C4464 303 409 3426 CERAMIC 0.1U K 16V
C4466 303 409 3426 CERAMIC 0.1U K 16V
C4467 303 409 3426 CERAMIC 0.1U K 16V
C4468 303 409 3426 CERAMIC 0.1U K 16V
C4469 303 409 3426 CERAMIC 0.1U K 16V
C447 303 369 0527 CERAMIC 0.01U K 25V
C4471 303 409 3426 CERAMIC 0.1U K 16V
C4472 303 409 3426 CERAMIC 0.1U K 16V
C4473 303 409 3426 CERAMIC 0.1U K 16V
C4474 303 409 3426 CERAMIC 0.1U K 16V
C4476 303 409 3426 CERAMIC 0.1U K 16V
C4477 303 409 3426 CERAMIC 0.1U K 16V
C4478 303 409 3426 CERAMIC 0.1U K 16V
C4479 303 409 3426 CERAMIC 0.1U K 16V
C448 303 369 0527 CERAMIC 0.01U K 25V
C4481 303 409 3426 CERAMIC 0.1U K 16V
C4482 303 409 3426 CERAMIC 0.1U K 16V
C4483 303 409 3426 CERAMIC 0.1U K 16V
C4484 303 409 3426 CERAMIC 0.1U K 16V
C4486 303 409 3426 CERAMIC 0.1U K 16V
C4487 303 409 3426 CERAMIC 0.1U K 16V
C4488 303 409 3426 CERAMIC 0.1U K 16V
C449 303 369 0527 CERAMIC 0.01U K 25V
C4491 303 409 3426 CERAMIC 0.1U K 16V
C451 303 369 0527 CERAMIC 0.01U K 25V
C452 303 369 0527 CERAMIC 0.01U K 25V
C453 303 369 0527 CERAMIC 0.01U K 25V
C454 303 369 0527 CERAMIC 0.01U K 25V
C456 303 369 0527 CERAMIC 0.01U K 25V
C457 303 369 0527 CERAMIC 0.01U K 25V
C458 303 369 0527 CERAMIC 0.01U K 25V
C459 303 369 0527 CERAMIC 0.01U K 25V
C4601 303 409 3426 CERAMIC 0.1U K 16V
C4602 303 397 5713 ELECT 100U M 10V
C4603 303 397 5713 ELECT 100U M 10V
C4606 303 342 3313 CERAMIC 0.1U K 25V
C4607 303 376 3112 ELECT 100U M 25V
303 374 7815 ELECT 100UM 25V
C4608 303 444 3310 CERAMIC 0.022U K 50V
C4609 303 409 3426 CERAMIC 0.1U K 16V
C461 303 369 0527 CERAMIC 0.01U K 25V
C4611 303 397 5713 ELECT 100U M 10V
C4613 303 409 3426 CERAMIC 0.1U K 16V
C4614 303 444 3310 CERAMIC 0.022U K 50V
C4616 303 397 5713 ELECT 100U M 10V
C4618 303 394 9318 ELECT 220U M 6.3V
303 387 5112 ELECT 220U M 6.3V
C4619 303 376 3112 ELECT 100U M 25V
303 374 7815 ELECT 100UM 25V
C462 303 369 0527 CERAMIC 0.01U K 25V
C463 303 369 0527 CERAMIC 0.01U K 25V
C464 303 369 0527 CERAMIC 0.01U K 25V
C466 303 369 0527 CERAMIC 0.01U K 25V
C467 303 369 0527 CERAMIC 0.01U K 25V
C468 303 369 0527 CERAMIC 0.01U K 25V
C469 303 369 0527 CERAMIC 0.01U K 25V
C471 303 369 0527 CERAMIC 0.01U K 25V
C472 303 369 0527 CERAMIC 0.01U K 25V
C473 303 369 0527 CERAMIC 0.01U K 25V
C474 303 369 0527 CERAMIC 0.01U K 25V
C476 303 369 0527 CERAMIC 0.01U K 25V
C477 303 369 0527 CERAMIC 0.01U K 25V
C478 303 369 0527 CERAMIC 0.01U K 25V
C479 303 369 0527 CERAMIC 0.01U K 25V
C4801 303 409 3426 CERAMIC 0.1U K 16V
C4802 303 409 3426 CERAMIC 0.1U K 16V
Key. No. Part No. Description

Sanyo PLV-Z3000 Specifications

General

Matrix size	0.7 \
Vertical scan range	50 - 100 Hz
Horizontal scan range	15 - 80 kHz
Projection technology	LCD
Contrast ratio (typical)	-
Screen size compatibility	40 - 300 \
Aspect ratio	16:9
RS-232 ports	1
Dimensions (WxDxH)	400 x 146 x 346 mm
Lamp type	UHP
Lamp power	165 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Focus	Manual
Focal length range	22.3 - 45.3 mm
Noise level	19 dB
Dot clock scanning frequency	100 MHz
Serial interface type	RS-232
Component video (YPbPr/YCbCr) in	3

Weight and Dimensions

Weight	7500 g
