Remote Control Unit (continued)
SAVE button This button fixes the temperature setting and reduces the operating
current to allow energy-conserving operation friendly to the
environment.
AMPERE button This button can be used to make it more difficult for the circuit
breaker to trip when the air conditioner is used with devices
consuming large amounts of power.
ADDRESS switch
•
The address switch changes to prevent mixing of signals from
remote control units when two Sanyo air conditioners are installed
next to each other. Normally, the address switch is set to A. When
switching the address, the remote control unit and People Sensor
must be changed, and the jumper cables on the indoor unit board
must be switched. For more information, please contact the dealer
where you made the purchase.
•
Normally, the tabs on the remote control unit should not bent, and
the address for the People Sensor should not be switched to B.
CLOCK button Press this button to set the current time.
MODE selector button
Green or red (AUTO)
Red (HEAT)
Orange (DRY)
Green (COOL)
Green (FAN)
Use this button to select the AUTO, HEAT, DRY, COOL or FAN mode.
: The air conditioner automatically selects the type of
operation (HEAT, DRY, COOL) suitable for the particular room
environment.
: The air conditioner makes the room warmer.
: The air conditioner reduces the humidity in the room.
: The air conditioner makes the room cooler.
: The air conditioner works only as a circulation fan.
FLAP buttons Press the
button either to select to set the airflow direction to
one of the six possible positions manually, or to select the sweep
function, which moves the flap up and down automatically.
: The airflow direction is set automatically.
: The airflow direction can be set manually. (six positions)
: The flap moves up and down automatically.
NOTE
To switch to the sweep function ( ) when in the manual ( ) mode,
hold down the FLAP button.
When
button is pressed, the vertical vanes swing so that air is
blown from side to side.
FAN SPEED selector
button
: The air conditioner automatically decides the fan speeds.
: High fan speed
: Medium fan speed
: Low fan speed
1 HR. TIMER button
(1-HOUR OFF TIMER)
: When you press this button, regardless of whether the unit is
operating or stopping, the unit operates for one hour and
then shuts down.
Reset (
) button
(ALL CLEAR)
Puts the remote control unit into pre-operation status. Always press
this button after replacing the batteries.
A/C SENSOR button When you press this button (use a small-tipped object such as a
ballpoint pen), the
mark will appear at the display. And the room
temperature is detected by the sensor which is built into the indoor
unit and the air conditioner is controlled accordingly.
NOTE
If the remote control is located near a heat source, such as a space
heater or in direct sunlight, press the A/C SENSOR button to switch
to the sensor on the indoor unit.
NOTE
The remote control unit sends the temperature signal to the air conditioner regularly at five
minute intervals. If the signal from the remote control unit stops for more than seventeen
minutes due to the loss of the remote control unit or other trouble, the air conditioner will
switch to the temperature sensor which is built into the indoor unit and control the room
temperature. In these cases, the temperature around the remote control unit may differ from
the temperature detected at the air conditioner’s position.
10 OI-275-10EG
OI275000
