Entris
®
BCE Operating Instructions 37
Technical Data
15.7 Warm-up Time
Unit Value
Device, approx. h 2
15.8 Interfaces
15.8.1 Specifications of the RS232 Interface
Type of interface: Serial interface
Interface operation: Full duplex
Level: RS232
Connection: D-sub connector, 9-pin
Maximum cable length: 10 m
Pin assignment
Pin 1: Not assigned
Pin 2: Data output (TxD)
Pin 3: Data input (RxD)
Pin 4: Not assigned
Pin 5: Internal ground
Pin 6: Not assigned
Pin 7: Clear to Send (CTS)
Pin 8: Request to Send (RTS)
Pin 9: Universal key
15.8.2 Specifications for the USB-C Interface
Communication: USB UTL
Connectable devices: Sartorius printers, Sartorius second display or PC
15.9 Device Dimensions
92
317
219
182
182
Fig. 5: Device dimensions for a precision balance in mm
