88
Practical Example
Totalize counted pieces
Settings (changes in the factory settings required for this example):
Setup: App: Application 1: Counting
Setup: App: Application 3: Totalizing: Evaluated values: Net + calculated
Setup: App: Application 3: Totalizing: Evaluation mode, MR function: Final evaluation, display + print
Step Key (or instruction) Display/Output
1. Turn on the balance and configure e
the settings as indicated above
2. Delete old totalization data, if necessary c
3. Tare the balance w
4. Toggle to Application 1: Counting d
5. Place the displayed number of Place parts to be counted
parts on the balance (here: 10 pcs) on the balance
6. Initialize the Counting application
Start soft key
7. Remove the reference sample Unload the balance
quantity and toggle to Totalizing d
8. Place a number of parts on the Place parts on the balance
balance (here: 50 pcs)
